Overview
Type-H1 is a chibi-style Live2D model designed for flexible character customization and expressive streaming use cases.
Required Software
To use this model, use software that supports Live2D Cubism SDK 5.0 / Cubism 5.0 models. VTube Studio is the primary tested application, and a basic VTube Studio setup file is included. For expanded tracking, VBridger is recommended.
Limitation
This customizable model has a fixed set of parts and part combinations, so it cannot generate every possible character design. Please use the customization parameter list as the official reference for what is included in this package.
Advanced edits (such as drawing new parts on textures) are possible, but they require image-editing and illustration experience.
Do not assume features from other customizable models are available here, since each model creator defines a different customization system.
File List
| Quantity | File | Category | Description |
|---|---|---|---|
| 1 | Type-H1\Type-H1.moc3 | Live2D Runtime | Model file |
| 1 | Type-H1\Type-H1.model3.json | Live2D Runtime | Model linking file |
| 1 | Type-H1\Type-H1.cdi3.json | Live2D Runtime | Parameter names |
| 1 | Type-H1\Type-H1.physics3.json | Live2D Runtime | Physics settings |
| 3 | Type-H1\Type-H1.4096\*.png | Live2D Runtime | Texture files |
| 2 | Type-H1\Motions\*.motion3.json | Live2D Runtime | Animation files |
| 70 | Type-H1\Expressions\*.exp3.json | Live2D Runtime | Expression files |
| 1 | Type-H1\Type-H1.vtube.json | VTube Studio | VTube Studio model setup file |
| 1 | Type-H1\icon.png | VTube Studio | Model icon |
| 1 | LICENSE.txt | Documentation | License agreement |
| 1 | 许可协议.txt | Documentation | License agreement (Chinese) |
| 9 | Sample Characters | Other | Preset characters |
Functional Toggle
Expression Toggle
Idle Animation
Tracking Parameter
You do not need every input parameter to receive data for tracking to work. In VTube Studio, some extended inputs may appear red when no tracker supplies them; the model still works with default face tracking (basic eye, mouth, head, and body motion).
For example, with a webcam tracker, Mouth X usually has no input. That is a limitation of webcam tracking. The mouth will not shift horizontally, but it will still smile and open because MouthSmile and MouthOpen are supported by most trackers.
For all available parameters, please refer to the official VTube Studio manual. Some plugins allow the user to add their own parameters to the tracking.
| Parameter | Type | Mapping / Requirement |
|---|---|---|
| EyeL Open | Face Tracking | Bind to EyeOpenLeft |
| EyeR Open | Face Tracking | Bind to EyeOpenRight |
| EyeL Smile | Face Tracking | Bind to MouthSmile |
| EyeR Smile | Face Tracking | Bind to MouthSmile |
| Eyeball X | Face Tracking | Bind to EyeRightX |
| Eyeball Y | Face Tracking | Bind to EyeRightY |
| BrowL Y | Face Tracking | Bind to BrowLeftY |
| BrowR Y | Face Tracking | Bind to BrowRightY |
| BrowL Form | Face Tracking | Bind to MouthSmile |
| BrowR Form | Face Tracking | Bind to MouthSmile |
| BrowL Angle | Face Tracking | Bind to BrowAngleL |
| BrowR Angle | Face Tracking | Bind to BrowAngleR |
| Mouth Form | Face Tracking | Bind to MouthSmile |
| Mouth Open | Face Tracking | Bind to MouthOpen |
| Mouth X | Face Tracking | Requires iOS tracking |
| CheekPuff | Face Tracking | Requires iOS tracking |
| Mouth Pucker | Face Tracking | Requires VBridger; bind to MouthPucker |
| Mouth Shrug | Face Tracking | Requires VBridger; bind to MouthShrug |
| Jaw Open | Face Tracking | Requires VBridger; bind to JawOpen |
| VoiceSilence | Lip-sync | Bind to VoiceSilence |
| VoiceA | Lip-sync | Bind to VoiceA |
| VoiceE | Lip-sync | Bind to VoiceE |
| VoiceI | Lip-sync | Bind to VoiceI |
| VoiceO | Lip-sync | Bind to VoiceO |
| VoiceU | Lip-sync | Bind to VoiceU |
| Angle X | Face Tracking | Bind to FaceAngleX |
| Angle Y | Face Tracking | Bind to FaceAngleY |
| Angle Z | Face Tracking | Bind to FaceAngleZ |
| Body X | Face Tracking | Bind to FaceAngleX |
| Body Y | Face Tracking | Bind to FaceAngleY |
| Body Z | Face Tracking | Bind to FaceAngleZ |
| Breath | Face Tracking | Auto-breathing |
| Mouse PositionX | Mouse Tracking | Bind to MousePositionX |
| Mouse PositionY | Mouse Tracking | Bind to MousePositionY |
| Ctr L B | Controller Tracking | Bind to ControllerShoulderLeft |
| Ctr L T | Controller Tracking | Bind to ControllerTriggerLeft |
| Ctr L SX | Controller Tracking | Bind to ControllerStickLeftX |
| Ctr L SY | Controller Tracking | Bind to ControllerStickLeftY |
| Ctr L SB | Controller Tracking | Bind to ControllerStickPressLeft |
| Ctr L StickON | Controller Tracking | Bind to ControllerThumbPosLeft |
| Ctr L UP | Controller Tracking | Bind to ControllerDPadY (up direction) |
| Ctr L Down | Controller Tracking | Bind to ControllerDPadY (down direction) |
| Ctr L Right | Controller Tracking | Bind to ControllerDPadX (right direction) |
| Ctr L Left | Controller Tracking | Bind to ControllerDPadX (left direction) |
| Ctr R B | Controller Tracking | Bind to ControllerShoulderRight |
| Ctr R T | Controller Tracking | Bind to ControllerTriggerRight |
| Ctr R SX | Controller Tracking | Bind to ControllerStickRightX |
| Ctr R SY | Controller Tracking | Bind to ControllerStickRightY |
| Ctr R SB | Controller Tracking | Bind to ControllerStickPressRight |
| Ctr R StickON | Controller Tracking | Bind to ControllerThumbPosRight |
| Ctr R UP | Controller Tracking | Bind to ControllerTriangle |
| Ctr R Down | Controller Tracking | Bind to ControllerCross |
| Ctr R Right | Controller Tracking | Bind to ControllerCircle |
| Ctr R Left | Controller Tracking | Bind to ControllerSquare |
Default Key Bindings (VTube Studio)
The default key bindings can be changed based on your own preferences in VTube Studio. See Hotkey Settings (Toggles) for more details.
| Category | Expression / Function | Default Hotkey |
|---|---|---|
| Tracking Mode | Default Mode | N/A |
| Tracking Mode | Controller Mode | Alt+C |
| Tracking Mode | Full Keyboard Mode | Alt+K+F |
| Tracking Mode | Half Keyboard Mode | Alt+K+H |
| Function | Reload Texture | LeftShift+R |
| Expression Toggle | Angry | LeftShift+1 |
| Expression Toggle | Blush | LeftShift+2 |
| Expression Toggle | Glasses | LeftShift+3 |
| Expression Toggle | Loading | LeftShift+4 |
| Expression Toggle | Question | LeftShift+5 |
| Expression Toggle | Sigh | LeftShift+6 |
| Expression Toggle | Star | LeftShift+7 |
| Expression Toggle | Idea | LeftShift+8 |
| Expression Toggle | Sweating | LeftShift+9 |
| Expression Toggle | Mic | LeftShift+M |
| Expression Toggle | Eyedark1 | E+1 |
| Expression Toggle | Eyedark2 | E+2 |
| Expression Toggle | Eyedizzy | E+3 |
| Expression Toggle | Eyedollar | E+4 |
| Expression Toggle | Eyeheart | E+5 |
| Expression Toggle | EyeOO | E+6 |
| Expression Toggle | Eyestar | E+7 |
| Expression Toggle | Eyetear | E+8 |
| Expression Toggle | EyeTT1 | E+9 |
| Expression Toggle | EyeTT2 | E+0 |
